Twyford Sola Thermostatic Basin Mixer

Required Product Products you may also need

SKU No. SA4255WH Twyford Sola 500mmW Medical Basin, 1 RH Tap Hole

Qty: 1 £225.56 RRP inc. VAT £225.56 RRP Inc VAT

RRP Inc VAT
Total £591.13

RRP inc. VAT
Total £492.61

Description

This Sola Thermostatic Basin Mixer is purpose-built for safety-critical environments such as hospitals, schools, and public facilities.

It combines modern design with precise thermostatic control, ensuring user protection from scalding while maintaining reliable water flow even in challenging plumbing systems.

Key Features:

• Thermostatic Safety Control – Pre-set at 38°C for safe use in public, semi-public and healthcare washrooms
• Single-Lever, Easy Operation – Smooth control for temperature and flow
• TMV3 & WRAS Approved – Fully compliant with NHS D08 and UK Water Supply Regulations
• Durable Build – Solid brass body with high-quality chrome finish
• Water-Saving Aerator – Flow regulated to 3.8 l/min at 3 bar
• Flexible Installation – Supplied with 350mm reinforced braided tails, check valves, and isolation valves
• Wide Compatibility – Works with gravity-fed, fully pumped, modulating combi boiler and unvented systems
• Maintenance Friendly – Replaceable thermostatic cartridge and simple recalibration process

Compliance & Safety:

• TMV3 certified – Suitable for healthcare, care homes, and public buildings
• WRAS approved – Meets UK water safety standards
• Fail-safe shutoff – Stops mixed flow instantly if either supply fails
• Preset to 38°C but can be calibrated to your system’s conditions

Perfect For:

• Healthcare & NHS facilities
• Schools & nurseries
• Offices & public washrooms
• Homes needing extra safety (elderly & children)

Installation Notes:

• Designed for one-hole basins
• Includes check valves & isolation valves for safe installation
• Hot inlet connects on the left, cold on the right (when facing the tap)
• Fully serviceable with easy access for cartridge replacement & recalibration

Technical Specifications:

• Mounting: Deck-mounted, single-hole
• Operation: Single lever with thermostatic mixer
• Height: 150mm
• Depth: 152mm
• Approvals: TMV3 & WRAS certified
• Body Material: Brass
• Max Hot Water Temp: 85°C
• Outlet Temp Range: 30°C – 50°C (preset 38°C)
• Operating Pressure: 0.5 – 10 bar (recommended 1–5 bar)
• Max Static Pressure: 12 bar
• Max Inlet Pressure (Dynamic): 5 bar
• Max Pressure Ratio: 5:1
• Flow Rate @ 3 bar: 3.8 L/min
• Inlet Connections: Flexible braided tails with check valves & isolation valves
• Dimensions: Ø45mm body

Key Features

• Thermostatic Safety Control
• TMV3 & WRAS Approved
• Water-Saving Aerator
• Single-Lever, Easy Operation
• For Healthcare Environments

Specification
