Stuart Turner Stuart CH Single Stage Boostamatic CH 12-14 B (50Hz)

46349

*Please note, you add your free product after adding the main product to the basket.

Description

Monsoon Extra are high flow rate pumps designed for meeting power showering and pressure boosting demands in larger homes; leisure centres and hotels. The Monsoon Extra universal 1.4 bar single pump is suitable for larger domestic and light commercial applications and can be installed into an open vented hot or cold water system where outlets are either above or below the level of the cold water cistern.

The Stuart Turner MONSOON EXTRA Universal 1.4 bar Single - Water Boosting Pump is a popular choice from the Stuart Turner Monsoon Extra Range.

Specification

Brand
Stuart Turner
Pump Connections
G 1" Male
Pump Current
1.8 Amps
Pump Cut In Pressure
0.8 bar
Pump Cut Out Flow
1 L/min
Pump Duty
Continuous
Pump Feet
Anti Vibration
Pump Flexible Hoses
300mm
Pump Flow Switch
1 L/min
Pump Fuse Rating
5 Amps
Pump Height
338mm
Pump Induction
Thermally protected
Pump Inlet Strainers
2 Supplied
Pump Length
273mm
Pump Maximum Air Temperature
40° C
Pump Maximum Inlet
8 metres
Pump Maximum Outlet
8 metres
Pump Maximum Suction
4.6 Metres
Pump Maximum Water Flow
120 L/min
Pump Maximum Working Pressure
5.0 bar
Pump Mechanical Seal
EPDM/PTFE/AI. Oxide
Pump Performance 1
Performance @ 30 l/min 1.2 bar
Pump Performance 2
Performance @ 90 l/min 0.7 bar
Pump Power Cable
1.5 metres
Pump Power Consumption
415 Watts
Pump Power Supply
230 V
Pump Pressure Vessel
13 psi
Pump Protection
IPX4
Pump Quiet Operation?
No
Pump Run Dry Protection
Yes
Pump Run On Timer
3 sec
Pump Type
Centrifugal
Pump Water Temperature
65° C
Pump Weight
8.7kg
Pump Width
159mm
Range
Monsoon Extra
