Description
Engineered with accessibility and strength in mind, this Geberit Duofix WC frame is the go-to solution for disabled-friendly bathrooms in private homes, care homes, hospitals, and commercial settings.
This frame is purpose built to accommodate wall-hung pans up to a 750mm projection, and is reduced in width allowing for support rails or handles, this makes it ideal for wheelchair users or those with mobility challenges.
With an adjustable WC installation height range of 410–460mmH, electrical compatibility for advanced hygiene features (like Geberit AquaClean shower toilets and touchless flush plates), and a strong, corrosion-resistant steel frame that can support up to 400 kg (63 stone) when combined with Geberit wall-hung pans, this unit delivers exceptional durability, hygiene, and peace of mind.
Key Features:
• Barrier-Free Design: Reduced frame width enables easy integration with grab rails or support arms
• Adjustable Height: WC seat height adjustable between 410–460 mm during installation
• Heavy-Duty Load Bearing: Strength-tested to support up to 400 kg (63 stone) when combined with Geberit wall-hung pans
• Electrical Ready: Supports plug-and-play upgrades like touchless flush, odour extraction, and AquaClean
• Ultra-Hygienic: Concealed cistern and no exposed pipework reduce dirt and bacteria build-up
• Silent Performance: Integrated acoustic solutions ensure quiet flush operation
Geberit has installed over 70 million cisterns globally, with every unit leak-tested before delivery. The one-piece blow-moulded cistern ensures long-lasting watertight performance, while easy maintenance access via the flush plate makes servicing fast and hassle-free.
Perfect for:
• Care Homes
• Hospitals
• Accessible/Disabled Bathrooms
• Modern Residential Installations
Compatible With:
• Geberit Sigma Flush Plates & Geberit Pneumatic Flush Buttons
• Geberit AquaClean Shower Toilets
• Geberit DuoFresh
Technical Specifications:
• WRAS Approved
• Flush Plate Compatibility: Geberit Sigma range (front actuation)
• Factory Flush Setting: 5.8 / 3 litres (adjustable up to 7.5L large / 4L small)
• Water Pressure Range: 0.1–10 bar
• Max Operating Temp: 25°C
• Frame Material: Powder-coated steel (corrosion-resistant)
• Cistern: Sigma 12 cm, insulated, EN 14055 Class II certified
What's Included:
• Water supply connection Rp 1/2" – R 1/2", MF-compatible, with integrated angle stop valve & hand wheel
• Protection box for service opening
• WC connection set, ø?90mm
• 90° connection bend (PE-HD, ø?90mm)
• Adaptor socket (PE-HD, ø?90/110 mm)
• 2 protection plugs & 2 threaded rods (M12)
• Fastening materials
Key Features
- Barrier-Free Design: Reduced frame width enables easy integration with grab rails or support arms
- Electrical Ready: Supports plug-and-play upgrades like touchless flush, odour extraction, and AquaClean
- Engineered with accessibility and strength in mind
- Solution for disabled-friendly bathrooms
- Perfect for private homes, care homes, hospitals, and commercial settings
